Check Specification & Cross-references
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
Specific attributes
| LeftF265863 | RightF265862 | |
|---|---|---|
| Basic Part Information | ||
| Alternate Part Name | Left Hand Tie Rod End, Tie Rod End Socket, Steering Tie Rob End | Right Hand Tie Rod End, Tie Rod End Socket, Steering Tie Rob End |
| OEM Part Number | 10QH248P4 | 10QH248P3 |
| Dimensional/Physical Attributes | ||
| Rod Thread Direction | Left Hand | Right Hand |
| Cross-references | ||
| Cross-references | 10QH248P4, 10QH310P1, 12004BNW0, 15584419, 18QK28A, 220TR115, 2452861, 310228, 310228E, 3634207, 685505, 838308B, 969055R91, A3144J296, A3144K297, ARE-9950, ARE9950, D0HZ3A131B, ES2041L, ES2116L, ES3057, ES376L, ES431L, FTR2116L, FTR3057, FTR376L, FTR431R, L24SV8202D16, L28SV5000A14, L28SV5000A18, L28SV5000H29, L28SV5000H35, L28SV5001A14, L28SV5001A18, L28SV6453A11, SP692235, SP692645, TE2021, TE2022, TE2045, R230071 | 10QH248P3, 10QH39P1, 15584420, 18QK214P2, 18QK23A, 18QK29301, 220TR116, 2452860, 310229, 310229E, 3634206, 685504, 839307B, 969056R91, A3144J296, A3144K297, ARE9990, ARE9991, D0H3A130B, D0HZ3A130B, ES2040R, ES2113R, ES2114R, ES2115R, ES3056, ES376R, ES431R, FTR2040R, FTR2113R, FTR2114R, FTR2115R, FTR376R, L24SV8203B16, L28SV5000A18, L28SV5001A18, L28SV5003B18, L28SV5004D1, L28SV6452A12, R230070, SP692234, SP692311, SP692644, TE2021, TE2022, TE2043, TE2044, TE2354, TE2453, 10QH248P2 |
Common Attributes14 attributes
| Basic Part Information | |
|---|---|
| Product Line | Steering Components |
| Category Name | Tie Rods & Ends |
| Part Type | Tie Rod End |
| Application/Fitment Attributes | |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| Mounting Location | Front Axle |
| Dimensional/Physical Attributes | |
| Material | Forged Steel |
| Rod End Thread Size | 1.125 in.- 12 |
| Stud Center to Rod End Length | 5.750 in. |
| Stud Thread Diameter | 0.875 in. - 14 |
| Taper Diameter - Large | 1.250 in. |
| Taper Diameter - Small | 1.080 in. |
| Taper Length | 1.36 in. |
| Technical/Performance Attributes | |
| Tie Rod Design Type | Straight |
| Packaging / Logistics Attributes: | |
| Net Weight | 4.66 lb. |
Intended Application
- Designed for use on front steer axles of heavy-duty commercial trucks. Compatible with Meritor MFS/FF series front axles in Class 6–8 truck applications.
- Mack: 10QH248P3
- Meritor: R230070
- Dana: SP692234
- Eaton: TE2021, TE2022, TE2043, TE2044, TE2354, TE2453
- Federal Mogul: ES3056, ES431R, L28SV5000A18
- Flagg: ES2114R, ES376R, ES431R
- Marmon: A3144J296
CrossReference(F265863 Left Side):
- Mack: 10QH248P4
- Meritor: R230071
- Dana: SP692235, SP692645
- Eaton: TE2021, TE2022, TE2045
- Federal Mogul: ES3057, ES431L, L28SV5001A14, L28SV5001A18, L28SV6453A11
- Flagg: ES2116L, ES376L, ES431L
- Marmon: A3144K297
Dimensions Not Available.
