Fortpro Air Spring F245587 offers a combination of durability, comfort, safety and cargo protection that makes it a reliable and efficient option for commercial vehicles. Their superior performance and benefits in terms of productivity and maintenance make them a popular choice in the transportation industry.
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
Basic Part Information5 attributes
| Product Line | Suspension |
|---|---|
| Category Name | Air Springs and Bags |
| Part Type | Rolling Lobe Air Spring |
| Alternate Part Name | Rolling Lobe Air Spring, Reversible Sleeve Air Spring, Air Suspension Bag, Suspension Air Bag, Pneumatic Spring, Air Ride Spring, Air Bag Suspension |
| OEM Part Number | W01-358-9069 |
Application/Fitment Attributes2 attributes
| Application Type | Heavy Duty Trucks, Semi-Trucks |
|---|---|
| VMRS Code | 016-008-000 |
Dimensional/Physical Attributes12 attributes
| Material | Fiber reinforced rubber bellows |
|---|---|
| Air Inlet Inside Thread | 1/2 NPT |
| Body Diameter | 10.12 in. |
| Bottom Plate Alignment | Parallel |
| Bottom Plate Diameter | 9.50 in. |
| Bottom Plate Stud | 1/2-13 UNC |
| Mounting Stud Configuration - Bottom | 1 |
| Mounting Stud Configuration - Top | 2 |
| Piston Height | 4.75 in. |
| Piston Material Type | Aluminum |
| Top Plate Diameter | 9.00 in. |
| Top Plate Stud | 3/8-16 UNC |
Technical/Performance Attributes3 attributes
| Air Spring Type | 1T Reversible Sleeve |
|---|---|
| Collapsed Length | 7.50 in. |
| Extended Length | 18.00 in. |
Packaging / Logistics Attributes:1 attribute
| Net Weight | 15.80 lb. |
|---|
Intended Application
- Peterbilt Heavy-Duty Vehicles with Air Trac Suspension
- Automann: 566CT64274, 566ER9069, AB1DK23I9069, AB1DK23IA312
- Contitech: 91014P312, 91014P312
- Dayton Parts Batco: 1R12069, 1R12669, 1R12676, 3529069
- Firestone: 9069, W013589069, W01-358-9069
- Goodyear: 1R12069, 1R12069, 1R12669, 1R12669
- Hendrickson: 9069, S13031
- Meritor: FS9069, MAF9069
