Fortpro Air Springs F245582 for Hendrickson and Mack (Early CH Models) is a high quality type of air suspension designed for commercial vehicles that require a strong and reliable suspension. These Air Springs offer greater driving comfort, stability and safety by absorbing shock and vibration from the road and providing additional support to the vehicle's suspension system.
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
Basic Part Information5 attributes
| Product Line | Suspension |
|---|---|
| Category Name | Air Springs and Bags |
| Part Type | Rolling Lobe Air Spring |
| Alternate Part Name | Suspension Air Bag, Air Bag Suspension, Reversible Sleeve Air Spring, Air Suspension Bag, Pneumatic Spring, Air Ride Spring, Rolling Lobe Air Spring |
| OEM Part Number | W01-358-9466 |
Application/Fitment Attributes2 attributes
| Application Type | Semi-Trucks, Heavy Duty Trucks |
|---|---|
| VMRS Code | 016-008-000 |
Dimensional/Physical Attributes13 attributes
| Material | Fiber reinforced rubber bellows |
|---|---|
| Air Inlet Inside Thread | 1/4-18 NPT |
| Air Inlet Outside Thread | 3/4-16 UNF |
| Body Diameter | 10.12 in. |
| Bottom Plate Alignment | 90 deg. |
| Bottom Plate Diameter | 10.00 in. |
| Bottom Plate Stud | 1/2-13 UNC |
| Mounting Stud Configuration - Bottom | 2 |
| Mounting Stud Configuration - Top | 2 |
| Piston Height | 4.88 in. |
| Piston Material Type | Composite |
| Top Plate Diameter | 9.00 in. |
| Top Plate Stud | 1/2-13 UNC |
Technical/Performance Attributes3 attributes
| Air Spring Type | 1T Reversible Sleeve |
|---|---|
| Collapsed Length | 8.10 in. |
| Extended Length | 20.00 in. |
Packaging / Logistics Attributes:1 attribute
| Net Weight | 19.60 lb. |
|---|
Intended Application
- Compatible with Ford (Aeromax, F650/F750) and Mack (CH, CX, GU series) Hendrickson HA/HA-360/400/460 (Rear Air Suspension)
- Automann: 566CT64276, AB1DK23K9466, AB1DK23KP442
- Contitech: 91016P410, 91016P410
- Dayton Parts Batco: 1R12365, 3529466, 49048002L
- Firestone: 9466, W013589466
- Goodyear: 1R12173, 1R12173, 1R12197, 1R12197, 1R12365, 1R12365, 1R12902
- Hendrickson: 49048000, 49048002, 490482, 49674000, 49674001, 49674002
- Mack: 364QS28, 57QL411M
