Fortpro Air Spring F245599 is a high quality air suspension system designed to improve the comfort, stability and load capacity of commercial and cargo vehicles. This air spring suspension uses a compressed air bag made of strong and durable materials, ensuring reliable performance over time.
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
| Basic Part Information | |||
|---|---|---|---|
| Product Line | Suspension | Category Name | Air Springs and Bags |
| Part Type | Rolling Lobe Air Spring | Alternate Part Name | Air Bag Suspension, Suspension Air Bag, Pneumatic Spring, Air Suspension Bag, Air Ride Spring, Rolling Lobe Air Spring, Reversible Sleeve Air Spring |
| OEM Part Number | W01-358-9039 | ||
| Application/Fitment Attributes | |||
| Application Type | Semi-Trucks, Heavy Duty Trucks | VMRS Code | 016-008-000 |
| Dimensional/Physical Attributes | |||
| Material | Fiber reinforced rubber bellows | Air Inlet Inside Thread | 1/4-18 NPT |
| Air Inlet Outside Thread | 3/4 16 UNF | Body Diameter | 10.12 in. |
| Bottom Plate Alignment | Parallel | Bottom Plate Diameter | 9.25 in. |
| Bottom Plate Stud | 1/2-13 UNC | Mounting Stud Configuration - Bottom | 1 |
| Mounting Stud Configuration - Top | 2 | Piston Height | 3.00 in. |
| Piston Material Type | Steel | Top Plate Diameter | 9.00 in. |
| Top Plate Stud | 1/2 13 UNC | ||
| Technical/Performance Attributes | |||
| Air Spring Type | 1T Reversible Sleeve | Collapsed Length | 4.40 in. |
| Extended Length | 13.50 in. | ||
| Packaging / Logistics Attributes | |||
| Net Weight | 15.25 lb. | ||
| Additional Information | |||
| Intended Application |
|
||
- Airtex: AB1DK23F9039
- Automann: 566CT64260
- Contitech: 91010P311, 91010P311
- Dayton Parts Batco: 1R12095, 1R12097, 3529039, S2063
- Firestone: 9039, W013589039, W01-358-9039
- Goodyear: 1R12095, 1R12095, 1R12097, 1R12097, 1R12097SA, 1R12122, 1R12122
